elevator guide rail with fishplate in rail

  • elevator guide rail with fishplate in rail
  • elevator guide rail with fishplate in rail
  • elevator guide rail with fishplate in rail
  • elevator guide rail with fishplate in rail

elevator guide rail with fishplate in rail

    Payment Type: L/C,T/T,Paypal,Money Gram,Western Union
    Terms of Trade: FOB,CFR,CIF,EXW
    Delivery Time: 15 Days
    Packaging: bundle
    Productivity: 20000 ton/month
    Brand: KOENIG
    Transportation: Ocean
    Place of Origin: China
    Supply Ability: 20000 ton/month
    Certificate: ISO9001
    HS Code: 8431310090

Basic Info

Model No.: KNG-T90-6

Product Description

The Guide Rail of elevator is made of stainless steeling. Machined guide rails elevator can be applied in elevator constructions. Elevator guild rails are high quality and low cost. we supply custom brand and size,according customer requests.Please contact us.

Our capacity of machined elevator rails clothing is about 20000ton/month. Guide elevator rail fish plate exported to all of the world. Many of domestic trading companies cooperated with us on machined elevator guides.

guide rail with fishplate

For all major sizes of elevator Guide Rail With Fishplate according to ISO, JIS and other standards as well as for Customer specific standard, reduced tolerances and special requirements are offered based on ride comfort and elevator speed application from around 4 m/sec to over 10 m/sec.

Reference Norm: ISO7465:2007/(GB/T 22562-2008·Raw material: E 275 BISO 630:1995),corresponding-to Fe 430 B. Guide rail length: 5000 mm ± 2mm. Different length according to Customer’s Requirements Different Guide Rails Sections And SpecificationsAccording To Definition With Customers.

guide rails elevator



Elevator Rail Guide Type Tolerance (GB/T 22562-2008 ISO 7465:2007)
b1 (±1.5) h1 (±0.75) h (±0.1) k (+3-0)
T45/A 45 45 5
T50/A 50 50 5
T70/B 70 65 64 9
T75/B 75 62 61 10
T78/B 78 56 55 10
T82/B 82.5 68.25 66.6 9
T82-3/B 82 62 61 15.88
T89/B 89 62 61 16
T90/B 90 75 74 16
T114/B 114 89 88 16
T125/B 125 82 81 16
T127-1/B 127 89 88 16
T127-2/B 127 89 88 16
T140-1/B 140 108 107 19
T140-2/B 140 102 101 28.6
T140-3/B 140 127 126 31.75



machined elevator guide rails


Standard Cold Drawn Guide Rails (elevator in rail)

KOENIG introduced cold drawn processing into the guide rail market at the end of the 40’s. Through continuous improvements and optimization in co-operation with the rolling mill, today on the market is available a complete range of cold drawn guide rails from 3 Kg/mt to 14 Kg/mt for application below two meters per second (400 feet for minute)and for average load capacity.

Reference Norm: ISO7465: 1997(E)/2001·Raw material: E 235 B (ISO 630:1 995), corresponding-to Fe 360 B. Guide rail length: 5000 mm ± 2mm. Different length according to Customer’s Requirements Different Guide Rails Sections And Specifications: According To Definition With Customers.

spare parts of guide rail

Standard Cold Machined Guide Rails

KOENIG Machined Guide Rail product range guides rails from 8 Kg/mt to 50 Kg/mt for usage in high load, high frequency, high speed
and special applications. KOENIG factories work towards a common standard, providing an enhanced riding Surface.

Reference Norm: ISO7465:2007/(GB/T 22562-2008·Raw material: E275 B (ISO 630:1995), corresponding-to Fe 430 B. Guide rail length:5000 mm ± 2mm.

elevator rail fish plate

High Quality Guide Rails

For all major sizes of machined guide rails according to ISO, JIS and other standards as well as for Customer specific standard, reduced tolerances and special requirements are offered based on ride comfort and elevator speed application from around 4 m/sec
to over 10 m/sec.

machined elevator rails kit

Reference Norm: ISO7465:2007/(GB/T 22562-2008·Raw material: E 275 BISO 630:1995),corresponding-to Fe 430 B. Guide rail length: 5000 mm ± 2mm. Different length according to Customer’s Requirements Different Guide Rails Sections And SpecificationsAccording To Definition With Customers.

Match Guide Rails

KOENIG Match guide rails have set a standard for the highest speed elevator market segment

Reference Norm: ISO7465:2007/(GB/T 22562-2008·Raw material: E 275 BISO 630:1995),corresponding-to Fe 430 B. Guide rail length: 5000 mm ± 2mm. Different length according to Customer’s Requirements Different Guide Rails Sections And SpecificationsAccording To Definition With Customers

elevator in rail

Hollow Guide Rails

Hollow guide rails are used for counterweight without Safety Gear.

Reference Norm: JG/t5072.3-1996

Raw material: excellent quality cold-roll steel sheets,tensile strength≥370mpa, strength of fastenings should not lower than the requirement of raw material.

Hollow Guide Rail length: 5000 ± 3mm.different length according to customer's requirements.

machined elevator rails kit


YC PRECISION TECHNOLOGY & MACHINERY CO.,LTD



YC INDUSTRY was established in 1999 which is specialized in manufacturing Steel rolling processing as well as CNC Cutting Machine. Develop up to now, We have 4 factories, and 2 of them are elevator guide rails manufactures, which covered more than 46,000 square meters.


With the automatic production lines of rolling mill and processing, the capacity of rolling mill is 22000-30000 Tons/month, and the capacity of processing is 8000-10000 Tons/month. Elevator Guide Rail and accessories have become our major business.
Due to the sufficient production capacity, we supply many well-known elevator companies and elevator guideway traders in China, enjoying a good reputation both at home and abroad and maintaining a long-term cooperative relationship.
In order to help more foreign elevator suppliers and elevator Guide Rail importers reduce procurement cost, we have now set up our own foreign trade department. At the beginning, we can give you a good price to win the market.
